The LMR® cable series includes LMR-400-UF-FR, a 50 Ohm coaxial cable built for indoor RF applications where flexibility and fire safety are essential. Featuring a stranded center conductor and a non-halogen, low smoke, fire-retardant jacket, it delivers outstanding performance in environments that require frequent bending or movement. With excellent durability and low loss characteristics, it’s ideal for installations demanding both reliability and safety
LMR-400 cable/stranded center conductor and FR PE jkt, listed CMR (PCC-FT4)
| Part NumberLMR-400-UF-FR |
| Environment |
| JacketFR-PE |
| Overall Diameter (mm)10.287 |
| Overall Diameter (in)0.405 |
| Weight Kg/m0.131 |
| Weight lb/ft0.088 |
| Operating Temp.°C (°F)
-40° to 85°C
(-40° to 185°F) |
| Min. Bend Radius (mm)25.4 |
| Min. Bend Radius (in)1 |
| Bending Moment (Nm)0.67835355 |
| Bending Moment (ft-lb)0.5 |
| Max Frequency (GHz)8 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
