LVT-196-SM
Stock Code: 3190-3554
SMA, male, straight connector for Levitate® 196
Inventory Status
| Distributor | Qty | Order |
Specifications
| Part NumberLVT-196-SM |
| Stock Code3190-3554 |
| InterfaceSMA |
| Gender Male (plug) |
| Orientation Straight |
| PIM Rating |
| Impedance (ohms)50 |
| Max Frequency (GHz)12.4 |
| VSWR Freq1.2 |
| VSWR Frequency (GHz)6 |
| Coupling NutHex |
| Inner Contact Attach |
| Outer Contact Attach |
| Body FinishElectroless Nickel |
| Pin FinishGold Plate, MIL-DTL-45204 |
| Length (mm)32.36 |
| Length (in)1.274 |
| Width (mm)9.15 |
| Width (in)0.36 |
| Weight (g)3.3 |
| Weight (lb)0.007 |
