TCA‑311501 is a high-temperature, low-loss coaxial cable built for critical aerospace, defense, navigation, and communication systems. Featuring exceptional flexibility and robust mechanical strength, it allows seamless routing through tight spaces while maintaining signal integrity. Ideal for collision-avoidance and mission-critical environments, this cable delivers reliable, long-lasting performance under extreme conditions.
TCA311501 0.057" Solid CC , 0.229" FEP Jacket
| Part NumberTCA-311501 |
| EnvironmentIndoor/Outdoor |
| JacketFEP |
| Overall Diameter (mm)5.81 |
| Overall Diameter (in)0.229 |
| Weight Kg/m0.0744 |
| Weight lb/ft0.05 |
| Operating Temp.°C (°F)
-55° to 200°C
(-67° to 392°F) |
| Min. Bend Radius (mm)30.48 |
| Min. Bend Radius (in)1.2 |
| Bending Moment (Nm) |
| Bending Moment (ft-lb) |
| Max Frequency (GHz)5 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
