PTSRB-141

The PhaseTrack®141 is a Semi-Rigid phase-stable coax assembly featuring a proprietary fluorocarbon dielectric, TF4®, eliminating the PTFE change phase occurring around 19 ºC. The PhaseTrack Semi-Rigid cable assemblies are perfect for in-the-box or extreme environment applications where stable phase over temperature is necessary.

Stock Code: AA-11278

PTSRB-141

Build your Assembly

This a factory assembled custom assembly. The cable and connectors are not available for individual sale.

Connector A
PTSRB-141
Connector B
Design Your Assembly

Specifications

Part NumberPTSRB-141
Environment
JacketCopper
Overall Diameter (mm)3.5814
Overall Diameter (in)0.141
Weight Kg/m0.0432
Weight lb/ft0.029
Operating Temp.°C (°F)-55° to 125°C
(-67° to 257°F)
Min. Bend Radius (mm)
Min. Bend Radius (in)0.425
Bending Moment (Nm)
Bending Moment (ft-lb)
Max Frequency (GHz)38.4
Impedance (ohms)50
Power Handling (DWV)

Part Number Structure

Cable Details
