TC-214P-SCM-RA-CC

Type SC, male (plug), straight, TC style connector for HPL-393, RG-393-NPP-SN, RG-213, RG-59, and SFT-393 type cables.

Stock Code: 3190-6870

SC, male, straight, with cable clamp

Request a Quote

Specifications

Part NumberTC-214P-SCM-RA-CC
Stock Code3190-6870
InterfaceSC
Gender male (plug)
OrientationStraight
PIM RatingNo
Impedance (ohms)50
Max Frequency (GHz)2.5
VSWR Freq1.3
VSWR Frequency (GHz)2.5
Coupling Nut
Inner Contact AttachSolder
Outer Contact AttachClamp
Body FinishAlbaloy
Pin FinishGold
Length (mm)79.15
Length (in)3.116
Width (mm)24.6
Width (in)0.969
Weight (g)
Weight (lb)
