QEAM-500
The QEAM-500 cable assembly is engineered for rugged, mission-critical defense applications requiring reeling and unreeling across extreme temperatures. Proven in systems like Hawk and Patriot Missiles, it offers reliable performance up to 10 GHz, excellent shielding, and durability. Its flame-retardant jacket and stainless-steel connectors ensure long-lasting operation in harsh, tactical environments.
Stock Code: AA-8019
QEAM-500 Quick Erecting Antenna Mast High Performance RF Cable
Request a Quote
Specifications
| Part NumberQEAM-500 |
| Environment |
| JacketFlame Retardant Polyurethane |
| Overall Diameter (mm)12.954 |
| Overall Diameter (in)0.5 |
| Weight Kg/m0.32 |
| Weight lb/ft0.215 |
| Operating Temp.°C (°F)-55° to 200°C (-67° to 392°F) |
| Min. Bend Radius (mm)69.85 |
| Min. Bend Radius (in)2.75 |
| Bending Moment (Nm) |
| Bending Moment (ft-lb)1.3 |
| Max Frequency (GHz)10 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
Part Number Structure
Cable Details
