MG-160-LSLT
MaxGain® 160-LSLT assemblies are high-performance, ultra-low-loss, low-smoke, low toxicity, microwave coaxial cables. Built with our unique spiral outer conductor technology, this lightweight cable is a reliable, high-frequency interconnect solution.
Stock Code: AA-11445
MaxGain-160-LSTS Low-Smoke, low-loss, high performance microwave coaxial cable
Build your Assembly
This a factory assembled custom assembly. The cable and connectors are not available for individual sale.
Specifications
| Part NumberMG-160-LSLT |
| Environment |
| JacketLow Toxicty Polyolefin |
| Overall Diameter (mm)4.953 |
| Overall Diameter (in)0.195 |
| Weight Kg/m0.0476 |
| Weight lb/ft0.032 |
| Operating Temp.°C (°F)-30° to 85°C (-22° to 185°F) |
| Min. Bend Radius (mm)28.956 |
| Min. Bend Radius (in)1.14 |
| Bending Moment (Nm) |
| Bending Moment (ft-lb) |
| Max Frequency (GHz)40 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
